Hunter Gatherer Frameset

View frame geometry
$1,500.00

Custom Built in the USA


Our custom frames are designed by Ride Endpoint and hand-built in Colbert, WA by Elephant Bikes. Please allow 6-8 weeks for Delivery.

A legend himself, Steve Crandall once rode to Philly on a clapped-out Nishiki mountain bike and it was 'almost the coolest shit ever.' During that ride, Steve dreamt of a different bike—a bike that would work way better than his old MTB and turn the ride into something way more rad. A few years ago we worked with Steve and the FBM Bike Co. to design and build the bike from that dream. That bike was the Hunter Gatherer, and this is the first big progression on that initial design.

Frame Design
The Hunter Gatherer is designed with more utility and long-range, technical mixed surface, loaded riding in mind. The Hunter Gatherer is a Columbus tubed steel frame designed for efficiency and comfort over the long haul with a geometry that puts the rider in a more relaxed position that translates to comfort and control while cruising through multi-day adventures over more aggressive terrain.

Tire Clearance & Wheel Standard
Shorter 435 chainstays maintain responsiveness while still providing improved clearance for 27.5x2.4 tires. The frame utilizes 12x142 thru-axle dropouts for the rear wheel and a 12x100 thru-axle dropout with our Search Light fork. The low trail fork is perfect for loaded riding without compromising control or confidence in handling.

Cargo & Fenders
The Hunter Gatherer has rear triangle and fork mounts for fenders and racks and is equipped with three bottle cages, mounted low to free up enough space for a frame bag.

The Hunter Gatherer is designed by Ride Endpoint and hand-built in Colbert, WA by Glen Copus at Elephant Bikes. Get one!

For questions about frame, fork, or custom build options, please Contact Us.





Frame specs

Frame Weight: 4 lb 10 oz - Size Small
Bottom Bracket: 68mm English Threaded
Headset: 1 1/8 Threadless
Front Axle: 12x100
Rear Axle: 12x142
Max Tire Clearance: 27.5 x 2.4
Max Rotor Size: 160F/160R
Seatpost: 27.2mm
Seatpost Clamp: 30.0mm
Fork Axle: 12x100mm
Rear Axle: 12x142mm (12x1.5 thread pitch, pre-2019 12x1.0 thread pitch)

Tube specifications:
28.6 x .8/.5/.8 Columbus Zona top tube
31.8 x .8/.5/.8 Columbus Zona down tube
28.6 Columbus Zona seat tube
4130 chromoly rear triangle

Geometry
All measurements in millimeters

Size

SM

MD

LG

XL

XXL

Reach

365

375

385

395

405

Stack

550

575

605

630

645

Top Tube Horizontal

533

550

570

588

602

Head Tube

123

140

180

200

220

Seat Tube Center to Center

450

500

520

540

560

Fork Axle to Crown

396

396

396

396

396

Fork Rake

70

70

70

70

70

Chainstay Length

435

435

435

435

435

Head Angle

73

73

73

73

73

Seat Angle

73

73

73

73

73

Bottom Bracket Drop

65

65

65

65

65

Trail

37

37

37

37

37
