Night Moves Frameset
Night Moves Frameset Night Moves Frameset Night Moves Frameset Night Moves Frameset Night Moves Frameset Night Moves Frameset Night Moves Frameset Night Moves Frameset Night Moves Frameset Night Moves Frameset Night Moves Frameset Night Moves Frameset Night Moves Frameset Night Moves Frameset Night Moves Frameset Night Moves Frameset Night Moves Frameset

Night Moves Frameset

View frame geometry
$1,500.00

In stock


Night Moves frames are in stock and painted to order. Paint takes 2-3 weeks depending on the queue.

Fast bikes with fat tires
Rando-rocketship, endurance all-road, ultralight tourer; affectionately referred to as the wiggle bike, the Night Moves is all of those things.

This frame is designed with smaller diameter Columbus Zona and Life double-butted tubes for a springy and all-day cush ride that doesn't compromise efficiency. Without too much deviation from our proven Coffee Grinder geometry, a marginally less aggressive position is achieved to keep you comfortable and efficient on those all-day (and night) rides.

Tire Clearance & Wheel Standard
Shorter 418 chainstays maintain responsiveness while still providing recommended clearance for 700x38 (32 with fenders) or 27.5x48 tires. The frame utilizes a 12x142 thru-axle for the rear wheel and a 12x100 thru-axle with our Search Light fork. Our Searchlight low trail fork is perfect for front-loaded riding without compromising control or confidence in handling.

Cargo & Fenders
Night Moves has rear triangle and fork mounts for fenders and racks and is equipped with three bottle cages, mounted low to free up enough space for a frame bag

Lighten up
For those who want to forego the extra luggage (and low-trail design), the Night Moves can be equipped with a carbon fork (700c wheels only) for an upcharge making it an equally capable endurance road bike and plays well with 700x28-38mm tires.

Gearing and other things of note:
Being optimized for long distances over surfaces you would likely call a "road", the Night Moves is designed for a 2x11 or 2x12 mechanical drivetrain.  Front derailleur placement is set to be compatible with a 50/34 compact down to a 46/30 sub-compact.   With a 38mm tire, Campagnolo 12-speed front derailleurs and early Shimano 11-speed units can end up being close to the rear tire.  Labeled tire size does not always match the effective size, so compatibility may vary.

Night Moves is designed by Ride Endpoint and hand-built in Boulder, CO by Pete Olivetti at Olivetti Bikes. See you after midnight!

For questions about frame, fork, or custom build options, please Contact Us.





Frame specs
Tube specifications:
28.6 x .8/.5/.8 Columbus Zona top tube
31.8 x .8/.5/.8 Columbus Zona down tube
28.6 Columbus Life seat tube
Columbus Zona rear triangle

Bottom Bracket: 68mm English Threaded
Headset: 1 1/8 Threadless
Front Axle: 12x100
Rear Axle: 12x142
Max Tire Clearance: 700x38 / 27.5 x 1.8 without fenders
Max Rotor Size: 160F/160R
Seatpost: 27.2mm
Seatpost Clamp: 30.0mm

Geometry

All measurements in millimeters

Size

SM

MD

MD/LG

LG

XL

Reach

378

384

390

402

420

Stack

540

571

580

620

640

Stack with Wolftooth Headset (16mm upper)

556

587

596

636

656

Stack with Cane Creeek Viscoset

563

594

603

643

663

Effective Top Tube

533

548

556

580

625

Headtube Without Headset Cups*

85

117

127

168

189

Headtube with Wolf Tooth Headset*

111

143

153

194

215

Headtube with Canecreek Viscoset/110

118

150

160

201

222

Seat Tube Center to Center

450

490

520

550

590

Seat Tube Center to Top

485

525

555

585

604

Fork Axle to Crown

396

396

396

396

396

Fork Rake

70

70

70

70

70

Chainstay Length

418

418

418

418

418

Head Angle

73

73

73

73

73

Seat Angle

74

74

74

74

74

Bottom Bracket Drop

72

72

72

72

72
